M5-.8x60 Class 8.8 Hex Cap Screws Zinc Clear

Product Description

Part Number: M5C60HCS88Z
Diameter/Pitch: M5-0.8
Length Under Head: 60MM
Grade: Class 8.8
Finish: Zinc Clear
Coarse / Fine Threads: Coarse
Partial / Full Threads: Partial
Wrench Size: 8MM

BoltsandNuts.com

M5-.8x60 Class 8.8 Hex Cap Screws Zinc Clear

SKU: M5C60HCS88Z

Product Description

Part Number: M5C60HCS88Z
Diameter/Pitch: M5-0.8
Length Under Head: 60MM
Grade: Class 8.8
Finish: Zinc Clear
Coarse / Fine Threads: Coarse
Partial / Full Threads: Partial
Wrench Size: 8MM

B&N Pro eligible item. Save 10% when you join Pro. Learn more.

Pack Size

1

$0.67/pc

Popular

50

$0.50/pc

100

$0.43/pc

250

$0.34/pc

Best Value

1900

$0.25/pc

$0.67

B&N Pro $0.00 Member Price

(Shipping $8.95) Add [amount] more for FREE SHIPPING

Free QR Storage Label Included with Most Items

Scan the QR and it will lead to that exact item for easy reordering!

30 Day Returns

Accepted on Most Items. Learn More

Diameter Pitch	M5-0.8
Grade Material	Class 8.8
Thread Class	6g
Head Height	3.5 mm nom
Clamp Load	6.2 kN
Proof Stress	580 MPa
Head Marking	"8.8" on head
Thread Length	16 mm ref

Length Under Head	60 mm
Finish	Zinc Clear
Width Across Flats	8 mm
Major Diameter	5 mm
Tensile Strength	800 MPa (116,030 psi)
Tensile Stress Area	14.2 sq mm
Torque Dry	6 Nm (5 ft-lb)
Inch Metric	Metric

Grade	Class 8.8
Partial Full Threads	Partial
Width Across Corners	9.2 mm max
Proof Load	8.2 kN (1,849 lbf)
Yield Strength	640 MPa
Hardness	22–32 HRC
Torque Lubricated	5 Nm (3 ft-lb)
