M12-1.75x20 Stainless Steel A2-70 Hex Cap Screws

Product Description

Part Number: M12C20HCSSS
Diameter/Pitch: M12-1.75
Length Under Head: 20MM
Grade: A2-70 Stainless Steel
Finish: Plain
Thread Series: Metric coarse
Threading: Fully threaded
Wrench Size: 19MM

BoltsandNuts.com

M12-1.75x20 Stainless Steel A2-70 Hex Cap Screws

SKU: M12C20HCSSS

Product Description

Part Number: M12C20HCSSS
Diameter/Pitch: M12-1.75
Length Under Head: 20MM
Grade: A2-70 Stainless Steel
Finish: Plain
Thread Series: Metric coarse
Threading: Fully threaded
Wrench Size: 19MM

B&N Pro eligible item. Save 10% when you join Pro. Learn more.

Pack Size

1

$1.55/pc

Popular

25

$1.16/pc

50

$0.99/pc

125

$0.79/pc

Best Value

350

$0.59/pc

$1.55

B&N Pro $0.00 Member Price

(Shipping $8.95) Add [amount] more for FREE SHIPPING

Free QR Storage Label Included with Most Items

Scan the QR and it will lead to that exact item for easy reordering!

30 Day Returns

Accepted on Most Items. Learn More

Thread Size	M12-1.75
Material	A2 Stainless (304-equivalent)
Thread Series	Metric coarse
Head Marking	A2-70 on head
Specifications Met	ISO 4017 / DIN 933, ISO 3506-1 A2-70

Length	20 mm
Finish	Plain
Threading	Fully threaded
Thread Class	6g

Grade	A2-70 Stainless
Wrench Size	19MM
Head Height	8 mm nom
Tensile Strength (min)	700 MPa (101,527 psi)

Technical Drawing

Not to scale · ISO 4017 / DIN 933 · See table for exact dimensions

Technical Dimensions

Length Under Head	20 mm
Major Thread Dia.	12 mm
Head Height	8 mm nom
Width Across Flats	19 mm
Thread Length	Fully threaded
Thread Class	6g
Min. Tensile Strength	700 MPa (101,527 psi)
Yield Strength	65,000 psi

Hex cap screw with a hexagonal head for external wrench engagement and a chamfered point for easier starting. The flat bearing surface distributes clamp load across the joint. Fully threaded shank, with ISO metric coarse threads.

Dimensions conform to ISO 4017 / DIN 933 and may vary within specified manufacturing tolerances.
